Twin hydrodynamic journal bearings

Extended tip technology compressor wheel

Twin scroll turbine housing

Adjustable compressor and turbine housing orientation

Compressor cover recirculation grooves

The bearing housings are not water-cooled and have a 1/4"NPT oil inlet.  The oil drain is the standard T3-T4 with M8 threads. Lines and fittings are all available here. Flanges and gaskets are available here.
